GOODWAY GLS-3300Y Turning Center
ConditionNouveau
Nouveau
With the latest machine tools technology and precision turning performance, GOODWAY brings you the new GLS series high-speed CNC turning center. Using 2 types of beds combined with super rigidity, high-speed turning capability, and compact size provides you with super-efficiency cutting power. The GLS series equipped with an optional live tooling turret, Y-axis, and sub-spindle can work on turning, milling, and drilling tasks at the same time to increase the output capacity with high-end value to meet your needs of today and tomorrow.
Key Features:
• 30˚ slant-bed design provides smooth chip disposal and easier operator access.
• Steel way covers and special steel wipers molded with industrial-strength rubber are used for durability.
• Fully enclosed splash guards keep chips and coolant contained for a safe clean working environment.
The auto lubrication system delivers metered amounts of lubrication to the slideways, ball screws, and vital components. Distribution is automatically shut off during idling to prevent waste.
FAGOR 8065 CN CONTROL
12" HYDRAULIC CYLINDER
12 STATION LIVE TOOLING TURRET, DRIVEN TOOL MOTOR 3.7/5.5KW), ID SHANK 40MM, OD SHANK 25MM, LIVE TOOL COLLET ER-32(1-20MM), MAX. SPEED 6000RPM, INCLUDING 1x0° & 90° DRIVEN TOOL HOLDER
CF-AXIS WITH DISK BRAKE ON MAIN SPINDLE (MAX SPEED 33rpm, TORQUE 240 n-m)
Y-AXIS (MAX. TURNING DIA. 400MM, MAX. X AXIS TRAVEL 270MM, +/-50MM, FEEDRATE MOTOR 2.7KW, Y AXES 12M/MIN, LINEAR WAY, X/Y AXES THRUST (CONT.) 961/961 kgf
HYDRAULIC TYPE LP-1 PROGRAMMABLE TAIL STOCK (QUILL/BODY ARE PROGRAMMABLE) (LIVE CENTER MT4) QUILL DIA. 70MM, QUILL TRAVEL 150MM, TAIL STOCK BODY TRAVEL 600MM
15 BAR COOLANT PUMP (KEEP STANDARD 3 BARS COOLANT PUMP, SWITCHING BY M CODE)
HIGH PRECISION LINEAR WAYS
C3 CLASS BALL SCREWS WITH PRETENSION ON ALL AXES
CHIP CONVEYOR (HINGE TYPE) WITH AUTO TIMER
COOLANT SYSTEM WITH GRUNDFOS 3/4 HP COOLANT PUMP RATED AT 55PSI (3 BARS)
HYDRAULIC SYSTEM
FULLY ENCLOSED SPLASH COVERS
ADVANCE AUTO LUBRICATION SYSTEM
TRI-COLOR SIGNAL TOWER(YELLOW/RED/GREEN)
HIGH INTESITY WORK LIGHT
M CODE AUTOMATIC POWER OFF
FOOT SWITCH FOR CHUCK
RS-232 INTERFACE
ELECTRIC CABINET HEAT EXCHANGER
FOUNDATION AND LEVELING KIT/MAINTENANCE TOOL KIT
