Nouveau APEC MTH-2452 | Bridge (Double Column) Vertical Milling Center

1.888.565.8807
sales@megatelcnc.com
ConditionNouveau

Aperçu

Taper:
Bridge (Double Column) Vertical Milling Center
Fabricant:
APEC
Modèle:
MTH-2452
Condition:
Build To Order
Statut:
À vendre

Description

Explore APEC MTH-2452's precision with 5,200 mm X-travel and robust 14T table load. Enhance capabilities with universal, mono, or fork head options. Ideal for complex milling with Heidenhain TNC640 control.

X-Axis Travel5,200 mm204.72"
Y-Axis Travel2,500 mm98.425"
Z-Axis Travel1,000 mm39.37"
Distance Between Column2,400 mm94.488"
Spindle Nose to Table Top1,150 mm45.276"
Table Size-X5,000 mm196.85"
Table Size-Y2,060 mm81.102"
Table Load Capacity14 T12,700.6 kg
Standard Spindle TaperHSK100AHSK100A
Standard Spindle Speed12,000 RPM12,000 RPM
Milling Head (2-axis) TypeUniversal head | Mono head | Fork HeadUniversal head | Mono head | Fork Head
A-axis Swivel185°185°
C-axis Rotation360°360°
ATC3232
Optional ATC40 | 6040 | 60
# Axis55
CN ControlHeidenhain TNC640Heidenhain TNC640
