GOODWAY GTZ-1500

Description

UPPER & LOWER TWIN TURRETS | TWIN Y AXES

When facing the dilemma of maintaining a highly efficient production while processing extremely complicated machining parts, the GOODWAY GTZ-1500 series is your best solution. This model is based on an ultra-solid 60° true slant bed, with the advanced structural design of twin spindles, twin Y-axis, and twin live tooling turrets. Any complex parts can be completed by a GTZ-1500 in a single setup. In addition, this series provides three bar diameters of Ø45 / Ø51 / Ø65 mm, satisfying your processing needs for various workpiece sizes.

Twin Y axes Control Function
• Y-axis control function can achieve simultaneous X, Y, Z, and C axes machining, which is capable of working on Y-axis off center milling, drilling, and tapping while improving the machining accuracy for multiple parts processing,
• The oblique design of the Y-axis structure allows this series to achieve a large Y-axis stroke ( Y1 = ± 42 mm, Y2 = ± 33 mm ) with a very small machine size.

One-piece Casting 60° True Slant Bed
• High rigidity which provides an extremely stable base for the spindle and turret.
• Shorten the distance between the operator and the working area.
• The independent guideway design of the Z1, Z2, and ZS axes effectively reduces movement restriction between each unit and ensures the maximum stroke of each axis.

Key Features:
✔ Advanced structural design of twin spindles, twin turrets, and twin Y axes.
✔ The extremely condensed floor space of 6.5 square meters, saves factory space and makes the production line more flexible.
✔ The upper and lower turret can be used simultaneously or separately to support spindle 1 and spindle 2 enabling more flexible machining.
✔ 12 or 24 stations turret, and a maximum of up to 48 tools ( 24 for live tools ).
✔ Automatic loading systems are available, such as gantry loading/unloading systems.
