AWEA SP-4016 BRIDGE TYPE VERTICAL MILLING CENTER
ConditionNouveau
1 disponible
Nouveau
Representing AWEA’s “The royal family of bridge machines” of mature manufacturing abilities and advanced technology skills, the SP series bridge-type vertical machining centers combine strong spindle power and high rigidity structure along with high-quality automation equipment and a full product line to provide you with high efficiency, high productivity machining strategies; it can be broadly applied in the automotive, precision mold, aerospace and energy industries.
Key Highlights:
✔ The modular spindle design provides cutting flexibility for various working conditions.
✔ High-rigidity roller-type linear guideways on the X, and Y axes offer heavy-duty cutting, fast movement, and low abrasion capabilities.
✔ The Z-axis is adopted with a high rigidity box way which is hardened and precisely ground suitable for heavy-duty cutting conditions. ( Opt. : The Z-axis can be adopted with roller-type linear guideways if equipped with a high-speed direct drive spindle. )
FANUC 0I-MF PLUS WITH 15” LCD SCREEN
FANUC MANUAL GUIDE I CONVERSATIONAL PROGRAM
FANUC AICCII (400 BLOCKS LOOK-AHEAD) + 2GB DATA SERVER
UPGRADE MAX NUMBER OF REGISTERABLE PROGRAMS 1000
AWEA I-CONSOLE SOFTWARE
RIGID TAPPING
JERK CONTROL
DISTANCE FROM SPINDLE NOSE TO TABLE TO: 200 - 960 MM
6,000 RPM GEAR DRIVEN SPINDLE, CAT50 BIG PLUS
SPINDLE MOTOR UPGRADE TO 40/50/72 HP, 1189 N-M HIGH TORQUE SPINDLE
60 TOOLS ATC MAGAZINE
500 PSI COOLANT THROUGH SPINDLE SYSTEM
COOLANT SYSTEM WITH PUMP AND COOLANT TANK
SPINDLE AIR CURTAIN
SPINDLE SIDE PROGRAMMABLE CUTTING AIR BLOW
SPINDLE OIL CHILLER
TWIN INTERNAL CHIP AUGER
CATERPILLAR TYPE CHIP CONVEYOR (47” DISCHARGE HEIGHT)
TWIN HYDRAULIC CYLINDER COUNTERBALANCE SYSTEM
AUTOMATIC LUBRICATION SYSTEM
ROOF ENCLOSURE SPLASH GUARD
DOOR INTERLOCK
MANUAL PULSE GENERATOR (MPG)
EMBEDDED ETHERNET AND RS-232 INTERFACE
M CODE AUTOMATIC POWER OFF
ELECTRICAL CABINET HEAT EXCHANGER
FOOTSWITCH FOR TOOL CLAMPING
WORK LIGHT
3-COLOR TOWER SIGNAL LIGHT
COOLANT GUN
FOUNDATION PADS & BOLTS KITS AND TOOL-BOX
OPERATION AND MAINTENANCE MANUALS
