SXKH HMG-120ES1411 DIE SPOTTING PRESS

Description

A Die Spotting Press provides a safe and efficient solution for checking the matching of the core and cavity of dies and molds. It allows operators to conveniently inspect, fit, adjust, and finish molds in one location while maintaining a comfortable and ergonomic working position.

1. Main Features:

Heavy-duty press construction with four 40Cr alloy steel columns.
Oil-free, self-lubricating graphite copper sleeves for cleaner operation and reduced maintenance.
High-standard machine configuration for reliable and accurate performance.
Upper platen can be tilted forward up to 180° for convenient mold inspection and servicing.
Shift-out lower platen with wear-resistant guide rails and heavy-duty dust protection.
Lower platen movement driven by an Eaton hydraulic motor with chain-drive structure for reliable operation and easy maintenance.
High-tensile tie rods provide increased accuracy and allow convenient platen parallelism adjustment during high-pressure mold closing.
Four mold-clamping cylinders provide balanced and consistent pressure during mold closing.
Electrical components comply with applicable CE, UL, and CSA standards.
Machine colors are available according to customer requirements.

2. Hydraulic and Electrical System:

Servo-hydraulic system equipped with high-performance hydraulic components for precise, smooth, and quiet operation.
High-quality hydraulic valve and oil pump system for reliable machine performance.
Siemens PLC controller and HMI for convenient machine parameter display and adjustment.
Energy-efficient, low-consumption LED lighting provides optimal illumination of the working area.

3. Mold Protection Function:

Proportional back-pressure system allows pressure to be adjusted according to the actual mold weight.
Low-pressure mold protection helps protect the mold during setup and closing operations.

4. Safety Design:

Anti-drop safety system with suspension-type protection for enhanced mold and machine safety.
Pneumatic-mechanical safety locks installed on both the right and left sides of the upper platen.
Integrated fault detection and alarm system for reliable machine monitoring.
Low-pressure mold protection function to help prevent mold damage.
Safety light curtains and safety fencing for enhanced operator protection.
Remote-control system for convenient machine operation.
