EVERISING S-300HB AUTOMATIC BAND SAW
ConditionNew
New
The EVERISING S-300HB is a fully automatic horizontal band saw designed for efficient, reliable production cutting of solid and bundled materials. Featuring a rigid pivot-type construction and automatic shuttle feeding system, the S-300HB delivers consistent cutting performance while reducing operator involvement for high-volume sawing applications.
The machine provides a 300 mm (12") round cutting capacity and 300 x 250 mm (12"W x 10"H) rectangular capacity. Its infinitely variable blade speed ranges from 20 to 100 m/min (65 to 330 fpm), allowing cutting conditions to be adjusted to suit different materials and applications.
The S-300HB incorporates hydraulic blade tensioning, a hydraulically controlled full-stroke dual-vise clamping system, and a floating shuttle vise for secure material handling throughout the automatic cutting cycle. The saw frame raising and lowering is controlled by a single lifting cylinder, while the automatic feed system supports repetitive production cutting.
STANDARD FEATURES:
SHUTTLE TYPE AUTOMATIC FEED
PLC CONTROL FOR ELECTRIC AND HYDRAULIC FUNCTIONS
HYDRAULICALLY CONTROLLED FULL-STROKE DUAL-VISE CLAMPING SYSTEM
FLOATING SHUTTLE VISE SYSTEM
INFINITELY VARIABLE SPEED CONTROL BY INVERTER
HYDRAULIC BLADE TENSIONING
ROLLER BEARING WITH CARBIDE BLADE GUIDE SYSTEM
PRESET CUT COUNTER WITH SHUT-OFF
OUT-OF-STOCK SHUT-OFF
IDLER WHEEL MOTION DETECTOR WITH BLADE STALLING AND BREAKAGE SHUT-OFF
FLUSHING HOSE FOR MACHINE CLEANING
WORK LIGHT
ONE M42 BI-METAL SAW BLADE
ONE SET OF TOOLS AND TOOL BOX
UNITED CONSTRUCTION – (BAR FEED AND SAW ARE ON ONE BASE)
SHUTTLE TYPE AUTOMATIC FEED
NCII
P.L.C. CONTROL FOR ALL ELECTRIC AND HYDRAULIC FUNCTION
HYDRAULICALLY CONTROLLED FULL STROKE DUAL VISE CLAMPING SYSTEM
FLOATING SHUTTLE VISE SYSTEM
SPLIT FRONT VISE
INFINITELY VARIABLE SPEED CONTROL BY INVERTER
BLADE SPEED TACHOMETER
HYDRAULIC BLADE TENSIONING
ROLLER BEARING WITH CARBIDE BLADE GUIDE SYSTEM
AUTOMATIC WORK HEIGHT CONTROL BY FAST APPROACH BAR SENSOR
PRESET CUT COUNTER WITH SHUT OFF
OUT-OF-STOCK SHUT OFF
MULTIPLE INDEXING (9 TIMES)
NESTING FIXTURE FOR BUNDLE CUTTING (HOLD-DOWN DEVICE)
POWER DRIVEN BLADE CLEANING BRUSH
IDLER WHEEL MOTION DETECTOR WITH BLADE STALLING AND BREAKAGE SHUT OFF
FLUSHING HOSE FOR MACHINE CLEANING
WORK LIGHT
ROLLER STOCK TABLE 2M LONG
ONE M42 BI-METAL SAW BLADE
ONE SET OF TOOLS AND TOOL BOX
AUTOMATIC CHIP CONVEYOR (FOR S-250HB, S-300HB)
USER FRIENDLY NC TOUCH SCREEN CONTROL WITH SELF-DIAGNOSTIC SYSTEM
