GOODWAY GS-3600LY - HORIZONTAL TURNING CENTER

Description

With the latest machine tools technology and precision turning performance, GOODWAY brings you the new GS series high-speed CNC turning center. Using 2 types of beds combined with super rigidity, high-speed turning capability, and compact size provides you with super-efficiency cutting power. The GS series equipped with an optional live tooling turret, Y-axis, and sub-spindle can work on turning, milling, and drilling tasks at the same time to increase the output capacity with high-end value to meet your needs of today and tomorrow.

Key Features:

• 30°low center gravity slant bed ensures high rigidity of GS-3000 series.
• X / Z axes adopt box ways structure and wide span design to ensure best rigidity and precision.
• Optional high precision built-in spindle or high power belt-driven spindle to meet any processing request.
• X / Z axes are directly driven by a high-performance AC servo motor, rapid feed rate can reach up to 30 m/min.
• 12-station servo index turret, adjacent and opposite tool changing only takes up to 0.3 and 0.8 sec.
• High-rigidity programmable tailstock or high-performance servo tailstock ensures the best support for the workpiece.
• Extra wide hardened and ground box ways are directly formed onto the machine bed and saddle during the casting process. They are precision machine and widely spaced for maximum strength. The box way design also provides the rigidity needed for heavy cutting and interrupted turning applications.
• The optional oil bath GERMAN made ZF 2-step gear box provides maximum torque up to 1,200 Nm, which can easily meet with heavy cutting requirements.
