TONGTAI THA-5000P Horizontal 4-axis Machining Center
ConditionNew
New
THA-5000P CNC Horizontal Turning Center
Expanded Power & Precision for Demanding Machining Applications
The THA-5000P delivers exceptional performance for high-precision horizontal machining of medium-to-large aluminum and cast iron parts. Built with a powerful 15,000 rpm direct-drive spindle and a spacious 500 × 500 mm dual-pallet rotary table, this machine offers robust capability for mass production and high-mix, low-volume operations alike.
With extended axis travel (730/730/830 mm in X/Y/Z) and a maximum workpiece capacity of Ø800 × H1000 mm, the THA-5000P is designed to handle larger, more complex parts with ease. The 0.001° indexing B-axis table, high-speed 40-tool ATC, and integrated APC system streamline operations while maximizing throughput.
Whether in the automotive, aerospace, or general machining industries, the THA-5000P provides the scale, speed, and smart functionality required for next-generation production lines.
Key Features:
• Spindle: High-torque 15,000 rpm direct-drive spindle with 37/15 kW power
• Travel & Speed: X/Y/Z stroke of 730/730/830 mm with 60 m/min rapid traverse
• B-axis Table: Precision 0.001° indexing, supports up to Ø800 × H1000 mm workpieces
• Automation Ready: Dual rotary pallet system with 500 kg load capacity per table
• Structural Integrity: Telescopic covers and central lubrication across all axes for durability
• Ergonomic & Efficient: Full splash guard, LED work lighting, and overhead coolant flushing for clean, safe operation
FANUC 0i-MF PLUS WITH 10.4" MONITOR
15000 RPM DIRECT DRIVEN SPINDLE, 37/15 KW, CAT40 DUAL CONTACT
40 TOOLS ATC MAGAZINE
SPINDLE COOLER
APC (ROTARY TYPE) WITH WORKING TABLE x 2 PCS
COOLANT UNIT
MACHINE ROOF OVERHEAD COOLANT FLUSHING SYSTEM
CHIP CONVEYOR (SCRAPER TYPE) H=1100 MM WITH TROLLEY
CENTRAL LUBRICATION FOR X/Y/Z AXIS
TELESCOPIC COVERS FOR X/Y/Z AXIS
STANDARD FULL SPLASH GUARD
ELECTRICAL CABINET WITH HEAT EXCHANGER
MANUAL PULSE GENERATOR
THREE COLOR WARNING LAMP
WORK LIGHT (LED)
DOOR INTERLOCK
RIGID TAPPING
COOLANT GUN
AIR GUN
THA-5000P CNC Horizontal Turning Center
Expanded Power & Precision for Demanding Machining Applications
The THA-5000P delivers exceptional performance for high-precision horizontal machining of medium-to-large aluminum and cast iron parts. Built with a powerful 15,000 rpm direct-drive spindle and a spacious 500 × 500 mm dual-pallet rotary table, this machine offers robust capability for mass production and high-mix, low-volume operations alike.
With extended axis travel (730/730/830 mm in X/Y/Z) and a maximum workpiece capacity of Ø800 × H1000 mm, the THA-5000P is designed to handle larger, more complex parts with ease. The 0.001° indexing B-axis table, high-speed 40-tool ATC, and integrated APC system streamline operations while maximizing throughput.
Whether in the automotive, aerospace, or general machining industries, the THA-5000P provides the scale, speed, and smart functionality required for next-generation production lines.
Key Features:
• Spindle: High-torque 15,000 rpm direct-drive spindle with 37/15 kW power
• Travel & Speed: X/Y/Z stroke of 730/730/830 mm with 60 m/min rapid traverse
• B-axis Table: Precision 0.001° indexing, supports up to Ø800 × H1000 mm workpieces
• Automation Ready: Dual rotary pallet system with 500 kg load capacity per table
• Structural Integrity: Telescopic covers and central lubrication across all axes for durability
• Ergonomic & Efficient: Full splash guard, LED work lighting, and overhead coolant flushing for clean, safe operation
Metric
| X-Axis Travel | 730 mm |
| Y-Axis Travel | 730 mm |
| Z-Axis Travel | 830 mm |
| Table Height From Floor | 1,150 mm |
| Max Workpiece Height | 1,000 mm |
| Max Workpiece Dia. | 800 mm |
| Spindle Center To Working Table Surface | 810 mm |
| Spindle Nose To Working Table Center | 900 mm |
| Table Size - X | 500 mm |
| Table Size - Y | 500 mm |
| Table Capacity | 500 kg |
| X/Y/Z Axis Rapid | 60/60/60 m/min |
| Spindle Speed | 15,000 RPM |
| Spindle Taper | CAT40 |
| Tool Magazine Capacity | 40 |
| Tool Length | 410 mm |
| Tool Weight | 10 kg |
| Max Tool Dia | 2,032 mm |
FANUC 0i-MF PLUS WITH 10.4" MONITOR
15000 RPM DIRECT DRIVEN SPINDLE, 37/15 KW, CAT40 DUAL CONTACT
40 TOOLS ATC MAGAZINE
SPINDLE COOLER
APC (ROTARY TYPE) WITH WORKING TABLE x 2 PCS
COOLANT UNIT
MACHINE ROOF OVERHEAD COOLANT FLUSHING SYSTEM
CHIP CONVEYOR (SCRAPER TYPE) H=1100 MM WITH TROLLEY
CENTRAL LUBRICATION FOR X/Y/Z AXIS
TELESCOPIC COVERS FOR X/Y/Z AXIS
STANDARD FULL SPLASH GUARD
ELECTRICAL CABINET WITH HEAT EXCHANGER
MANUAL PULSE GENERATOR
THREE COLOR WARNING LAMP
WORK LIGHT (LED)
DOOR INTERLOCK
RIGID TAPPING
COOLANT GUN
AIR GUN
