APEC MCM-13200 5-Axis High-Speed Gantry Machining Center

Description

The APEC MCM-13200/5R is a high-speed 5-axis gantry machining center designed for large-scale and high-precision applications such as aerospace structures, mold machining, and aluminum alloy components. Engineered for superior rigidity, long travel ranges, and simultaneous 5-axis performance, this machine delivers unmatched efficiency and flexibility across complex, multi-sided part geometries.

Powered by a 24,000 RPM HSK63A spindle, the MCM-13200/5R offers high-speed cutting with exceptional stability, making it ideal for demanding operations. The built-in AGA 2-axis milling head (A/C-axis) enables ±125° and ±360° rotation respectively, allowing for intricate undercuts and contouring on free-form surfaces. Its high clamping torque (4,000 Nm) ensures rigidity during heavy cutting.

With an extended X-axis travel of 20,000 mm, Y-axis of 1,500 mm, and Z-axis of 850 mm, the MCM-13200/5R supports long-part machining with impressive positioning accuracy. Integrated Heidenhain TNC640 5-axis CNC control with HR510 MPG guarantees precise multi-axis synchronization and optimized surface finishes.

Key features include:

• 24,000 RPM spindle with 35/42 kW power and 56/67 Nm torque
• Dual 32-tool ATC magazines (HSK63A) for extended tooling flexibility
• Rack & pinion X-axis drive and ball screw Y/Z-axes for high-speed travel (40 m/min X, 30 m/min Y/Z)
• ±0.03 mm TCPM 5-axis accuracy with optical scale feedback on all axes
• Custom 20,000 x 800 mm table with dual hydraulic zones (10m each) and divider panel
• High-rigidity guideways, spindle chiller, oil mist collection, and air-conditioned electrical cabinet

Built for large-format machining with precision and reliability, the MCM-13200/5R is a future-ready solution for manufacturers who need to scale production, improve surface quality, and maintain tight tolerances on large or complex parts.
