The Tongtai TD-2500YBC is a next-generation multi-tasking CNC turning center engineered to deliver high-precision performance for complex part production. Designed to meet the evolving demands of the aerospace, automotive, and precision machining industries, the TD-2500YBC offers improved rigidity, increased tool capacity, and enhanced structural dynamics for reliable operation and superior machining quality.
Building upon the rigidity of the renowned TB series, the TD-2500YBC introduces a robust 75-degree slant bed structure, lowering the machine’s center of gravity while maintaining excellent chip evacuation and ergonomic accessibility. Its real linear Y-axis design, featuring a symmetrical saddle and true perpendicular X/Y/Z axes, enables advanced milling capability and optimized servo compensation—ensuring accurate tool positioning and exceptional straightness.
The standard configuration includes a 12-station BMT-65 power turret capable of live tooling at up to 6,000 RPM, with optional upgrades to a 16-station turret for extended tooling flexibility. The machine also supports an optional sub-spindle with a high-speed built-in motor and synchronous temperature control to prevent thermal distortion during long machining cycles.
Constructed entirely from high-grade cast iron, and validated through Finite Element Analysis (FEA), the TD-2500YBC's structure is optimized for dynamic rigidity and vibration dampening—ideal for high-tolerance, multi-process applications.
Key Features:
• 75° slant bed design for enhanced structural rigidity and chip flow
• Real linear Y-axis with symmetrical saddle for high milling accuracy
• High-rigidity cast iron frame with FEA-optimized design
• 12-station BMT-65 live tooling turret (16-station optional)
• Max. live tool speed up to 6,000 RPM
• Rapid turret indexing time: 0.3 sec (adjacent), 1 sec (opposite)
• Main spindle with 10″ chuck, Ø130 mm bearing, and up to 3,500 RPM
• Optional sub-spindle with 6″ chuck and up to 5,000 RPM
• CS-axis rotary encoder with 0.001° indexing for complex angular machining
• Sub-spindle cooler with thermal distortion prevention
• Servo compensation on all axes for superior positioning accuracy
FANUC 0i-TF PLUS WITH 10.4" LCD SCREEN
3500 RPM BELT-DRIVEN TYPE (MAIN SPINDLE)
POWER TURRET WITH VDI-40 RADIAL TYPE TOOL DISC 12 STATIONS
WITH SPINDLE MOTOR 5.5/3.7 KW AND MAX. SPEED 6000 RPM
SOFT JAWS (FOR MAIN SPINDLE 8" CHUCK) × 1 SET
SOFT JAWS (FOR SUB SPINDLE 6" CHUCK) × 1 SET
X/Y/Z/W AXIS STROKE 230/±51/700/700 MM
X/Y/Z/W AXIS RAPID TRAVERSE 30/15/36/36 M/MIN
WITHOUT TAILSTOCK
WORKPIECE CONVEYOR
CHIP CONVEYOR H=1100 MM WITH TROLLEY
HYDRAULIC UNIT FOR CHUCKS WITH AIR COOLER
STANDARD SPLASH GUARD
ELECTRICAL CABINET WITH HEAT EXCHANGER
COOLANT UNIT
PART CATCHER
PART EJECTOR ON SUB SPINDLE
BAR FEEDER INTERFACE
OIL SKIMMER
RENISHAW HRPA TOOL PRESETTER FOR MAIN & SUB SPINDLE
COOLANT GUN WITH PUMP & ON/OFF SWITCH
TURNING TOOL HOLDER PACKAGE × 1 SET
2 x PCS FACING TOOL HOLDER (1")
2 x O.D. TOOL HOLDER (1")
2 x I.D. TOOL HOLDER (DIA. 1-1/2")
4 x O.D. TOOL GASKET
6 x BORING SLEEVE (DIA. 3/8", 1/2", 5/8", 3/4", 1", 1-1/4" MM)
3 x DRILLING SLEEVE (MT#1, 2, 3)
2 x VDI-40 AXIAL TYPE (90 DEGREE) LIVE TOOL HOLDER
2 x VDI-40 RADIAL TYPE (STRAIGHT) LIVE TOOL HOLDER
