EVERISING P-150ILA AUTOMATIC CIRCULAR SAW MACHINE
ConditionNew
New
The EVERISING P-150ILA Circular Saw is a premium billet-cutting machine designed for high-volume and high-precision industrial applications. Engineered for performance and durability, this machine features a linear slide horizontal feed system and servo-driven saw head action for exceptional cutting accuracy and control. The user-friendly touchscreen interface ensures simplified operation, while the servo motor-driven length index system, combined with a ball screw mechanism, guarantees precise material positioning. The P-150ILA comes equipped with hydraulic front and vertical vises for firm clamping, a floating shuttle device for handling bent bars, and a hydraulic sorting chute for efficient part discharge. Additional features include an inner brake transmission system, an inverter-controlled variable blade speed, a servo-powered saw head feed system, and an oil mist cooling system for blade longevity.
The standard package includes a 5-meter automatic round bar loading table (for bars between 2M and 6M in length), a chain-type chip conveyor, a hydraulic power-driven brush, and an air-cooling gun specifically for the P-150ILA. The machine is supplied with two saw blades (one for testing and one brand new), a transmission belt set, 5 gallons of cutting mist oil, and a complete tool kit with a toolbox. Built for efficiency, reliability, and operator convenience, the EVERISING P-150ILA is the ideal solution for manufacturers seeking a heavy-duty CNC circular saw that delivers superior performance, reduced downtime, and cost-effective production.
Key Features:
• Linear slide horizontal cutting with servo motor feed
• Touchscreen control for easy and intuitive operation
• Accurate length index system powered by ball screw and servo motor
• Hydraulic clamping front and vertical vises
• Floating shuttle device for bent bar handling
• Automatic bar loading table for 2M–6M round bars (lifting type)
• Inverter-controlled variable blade speed
• Oil mist blade cooling and air cooling gun for blade
• Hydraulic sorting chute for cut-off management
• Chain-type chip conveyor and hydraulic power brush
• Includes saw blades, mist oil (5 gallons), transmission belt, and tool kit
INNER BRAKE TRANSMISSION SYSTEM.
THE SAW HEAD ACTION/CUTTING DIRECTION IS LINEAR SLIDE (HORIZONTAL) FEEDING WAY
FRIENDLY AND EASY TO OPERATION TOUCH SCREEN.
ACCURATE LENGTH INDEX DEVICE, DRIVE BY SERVOMOTOR AND BALL SCREW
HYDRAULIC CLAMPED FRONT & VERTICAL VISES.
FLOATING SHUTTLE DEVICE.
HYDRAULIC SORTING CHUTE.
SCRAPER, CHAIN TYPE CHIP CONVEYOR
SAW HEAD FEED SYSTEM VIA SERVO MOTOR AND BALL SCREW
OIL MIST COOLING SYSTEM.
INFINITELY VARIABLE BLADE SPEED CONTROLLED BY INVERTER.
AUTOMATIC LOADING TABLE (5M) ONLY FOR ROUND BAR (FOR 6M LONG BAR) - LIFTING TYPE
LOADING LENGTH LIMIT : 2M TO 6M LONG MATERIAL
UNDER 300MM LENGTH MATERIAL CAN'T CUT IN SINGLE AND AUTOMATIC CUTTING MODE.
SAW BLADE 2PCS (ONE IS USED FOR TESTING ON THE MACHINE THE OTHER IS BRAND NEW).
POWER DRIVEN BRUSH FOR P-50ILA, P-75ILA AND P-100ILA
HYDRAULIC MOTOR POWER BRUSH FOR P-150ILA
NO AIR COOL GUN FOR BLADE FOR P-50ILA, P-75ILA AND P-100ILA
AIR COOL GUN FOR BLADE FOR P-150ILA
TRANSMISSION BELT X 1 SET
CUTTING MIST OIL 5 GALLONS
ONE SET OF TOOLS AND TOOL BOX
OPTIONAL ACCESSORIES:
P-150ILA MODIFY TO CUT MAX. 160MM WITH 480MM BLADE (P-160ILA)
P-150ILA MODIFY TO CUT MAX. 180MM WITH 520MM BLADE (P-180ILA) WITH LIFTING TYPE LOADING TABLE
