High-Speed Precision for Large-Part Machining
The AWEA VP-2016 is a high-performance vertical machining center designed for speed, precision, and structural rigidity—making it ideal for industries such as aerospace, automotive, mold & die, and precision component manufacturing. With its generous travel size of 2,000 mm (X), 1,600 mm (Y), and 800 mm (Z), this machine is built to handle large, complex workpieces with consistent accuracy.
Its high-speed linear guideway design across all axes ensures rapid movement with reduced friction, while the wide base and reinforced column provide the rigidity required for stable cutting and extended tool life. The AWEA-designed belt or direct-drive spindle offers reliable power for both roughing and finishing applications. Combined with a dual-screw Y-axis structure, large-pitch ball screws, and FANUC servo drive system, the VP-2016 delivers outstanding accuracy even under high-load conditions. This machine is ideal for aerospace structures, large molds, and heavy-duty components
Whether you're machining oversized molds, die bases, or structural aerospace parts, the AWEA VP-2016 offers the flexibility and high-performance foundation required for large-format, high-speed CNC milling.
Key Features:
• Large travel range: X = 2,000 mm, Y = 1,600 mm, Z = 800 mm
• High-speed linear guideways on all axes for fast, smooth motion
• Dual Y-axis ball screw design for balanced, stable cutting
• Reinforced wide-column structure for increased rigidity
• High-power spindle options (belt or direct-drive)
• Precision ground ball screws with pre-tension for thermal stability
• FANUC CNC control with servo direct-drive system
FANUC 0I-MF CONTROL WITH 10.4” LCD SCREEN
FANUC MANUAL GUIDE-I CONVERSATIONAL PROGRAMMING
AICCII (200 BLOCKS LOOK AHEAD)
PARTS PROGRAM STORAGE SIZE 2MB
MAX NUMBER OF REGISTERABLE PROGRAMS 1000
JERK CONTROL
SMOOTH TOLERANCE CONTROL
4 SPARE M-CODE M190~M197
FANUC ALPHA22i SPINDLE MOTOR, 30/35/47/60HP (CONT. / 30 MIN/2.5 MIN/ PEAK
6,000RPM GEAR DRIVEN SPINDLE
UPGRADED TO CAT-50 BIG PLUS
UPGRADED TO 60 TOOLS ATC MAGAZINE
500psi COOLANT THROUGH SPINDLE SYSTEM, CTS PREP WITH UNION
COOLANT SYSTEM WITH PUMP AND TANK
ROOF ENCLOSURE SPLASH GUARD
DOOR INTERLOCK
CENTRALIZED AUTOMATIC LUBRICATING SYSTEM
AUTOMATIC POWER OFF SYSTEM
TWIN INTERNAL CHIP AUGERS
CATERPILLAR TYPE CHIP CONVEYOR WITH 47” DISCHARGE HEIGHT, NO CHIP CART
FOOTSWITCH FOR TOOL CLAMPING
MANUAL PULSE GENERATOR
RS 232 INTERFACE & EMBEDDED ETHERNET INTERFACE
SAFETY SWITCH
3 COLOR TOWER LIGHT
FOUNDATION BOLT KIT, TOOLBOX, AIR GUN
OPERATION AND MAINTENANCE MANUALS, PART LIST, ELECTRICAL DRAWINGS
