GOODWAY GLS-3300MS Turning Center
ConditionNew
New
With the latest machine tools technology and precision turning performance, GOODWAY brings you the new GLS series high-speed CNC turning center. Using 2 types of beds combined with super rigidity, high-speed turning capability, and compact size provides you with super-efficiency cutting power. The GLS series equipped with an optional live tooling turret, Y-axis, and sub-spindle can work on turning, milling, and drilling tasks at the same time to increase the output capacity with high-end value to meet your needs of today and tomorrow.
Key Features:
• 30˚ slant-bed design provides smooth chip disposal and easier operator access.
• Steel way covers and special steel wipers molded with industrial-strength rubber are used for durability.
• Fully enclosed splash guards keep chips and coolant contained for a safe clean working environment.
The auto lubrication system delivers metered amounts of lubrication to the slideways, ball screws, and vital components. Distribution is automatically shut off during idling to prevent waste.
FANUC 0i-TF PLUS CONTROL WITH 10.4" LCD SCREEN
MANUAL GUIDE I FOR FANUC 0i-TF PLUS
FANUC ALPHA P22 SPINDLE MOTOR 11/15KW
12 STATION LIVE TOOLING TURRET, DRIVEN TOOL MOTOR 3.7/5.5KW) ID SHANK 40MM, OD SHANK 25MM, LIVE TOOL COLLET ER-32 (1-20MM), MAX. SPEED 6000 RPM
- 1 SET x FACE TOOL HOLDER LN-3197
- 6 SETS x FACE CUTTING HOLDER LN-3195
- 6 SETS x THROW-AWAY DRIIL HOLDER LV-3191
- 1 SET x CUT OFF TOOL HOLDER LN-3199
- 1 SET x BORING BAR SLEEVE (CJ-3010/CJ-3011) MT2/MT3
- 1 SET x THROW-AWAY DRILL SOCKET (CV-3203A/B/C/D) & CV-3205A/B/C/D DIA. 6/8/10/12/16/20/25/32MM
CF-AXIS WITH DISK BRAKE ON MAIN SPINDLE
8" CHUCK SIZE SUB-SPINDLE WITH CYLINDER (TAIWAN MADE) USD 23,950 WITH BAR CAPACITY 51MM, MAX. SUB-SPINDLE SPEED 5000RPM, SPINDLE NOSE A2-6, BELT TYPE SPINDLE MOTOR, POWER 7.5/11KW
CS-AXIS WITH DISK BRAKE ON SUB-SPINDLE
LINEAR GUIDEWAYS ON ALL AXES
CHIP CONVEYOR (HINGE TYPE) WITH AUTO TIMER HEIGHT 1200MM
20 BAR COOLANT PUMP (300 PSI)
ELECTRICAL CABINET HEAT EXCHANGER
12" TAIWAN MADE 3 JAWS BIG BORE WITH ONE SET EA. SOFT & HARD JAWS
PARTS CATCHER (FOR PARTS MAX. DIA. 60 x 180MM, MAX. WEIGHT 4KGS)
AUTO RENISHAW TOOL SETTER (FOR MAIN SPINDLE) HPMA
2 SETS x 0° LIVE TOOL HOLDER ER-32/EC
2 SETS x 90° LIVE TOOL HOLDER ER-32/EC
OIL SKIMMER
CHIP CART
