BEMATO BMT-1850EN CONVENTIONAL LATHE
ConditionNew
New
Machine Features:
• Headstock Machines are built with hardened/ground gears in the headstock, high precision bearing, and oil cooler to provide the highest spindle speed and high accuracy turning. Machines are equipped with automatic spindle-speed change for the most efficiency and productivity.
• Bed Machines use high-performance cast iron with hardening and ground to ensure high-precision/rigid cutting.
• The Control Console is located in an independent way to allow moving quickly and effortlessly A removable Handwheel is equipped at the side of the control console for convenience and efficient operating setting.
FANUC 0i-TF PLUS CONTROL WITH 10.4" COLOR LCD SCREEN
β8i SPINDLE SERVO MOTOR, WITH: MANUAL GUIDE i
AUTOMATIC LUBRICATION IN HEADSTOCK AND SLIDE WAYS & BALL SCREWS
AUTOMATIC SPINDLE SPEED GEAR CHANGER
CUTTING FLUID COOLANT SYSTEM
FULL LENGTH REAR SPLASH GUARD
FRONT MOVEABLE CHIP TROLLEY
FULL ENCLOSED END GUARD
LED WORKING LIGHT
LEVELING BLOCKS
CENTERS AND CENTER SLEEVE
SERVICE TOOLS & TOOLBOX
OPERATION, PROGRAMMING & INSTRUCTION MANUAL
OPTIONAL ACCESSORIES:
10" SK TYPE DIRECT MOUNTED HEAVY DUTY 3-JAW SCROLL, CHUCK (MAX. SPEED: 2800 rpm)
SOFT JAWS FOR 8"/9"/10" 3-JAW CHUCK
10" DIRECT MOUNTED 4-JAW INDEPENDENT CHUCK
ELECTRIC 8-STATION AUTO. TOOL CHANGER TURRET BTP-63, FRONT MOUNT (INDIA MADE)
CHAIN TYPE CHIP CONVEYOR WITH TAIL-END EXIT
NEW DESIGN ROUND TYPE GUARDING
Machine Features:
• Headstock Machines are built with hardened/ground gears in the headstock, high precision bearing, and oil cooler to provide the highest spindle speed and high accuracy turning. Machines are equipped with automatic spindle-speed change for the most efficiency and productivity.
• Bed Machines use high-performance cast iron with hardening and ground to ensure high-precision/rigid cutting.
• The Control Console is located in an independent way to allow moving quickly and effortlessly A removable Handwheel is equipped at the side of the control console for convenience and efficient operating setting.
Metric
| SWING OVER CROS SLIDE | 285" |
| SWING IN GAP | 25" |
| SWING OVER BED | 18.11" |
| BED WIDTH | 12.52" |
| DISTANCE BETWEEN CENTERS | 40.433" |
| GAP WIDTH FROM FACEPLATE | 6.4961" |
| SPINDLE BORE | 2.126" |
| SPINDLE NOSE | D1-6 |
| SPINDLE SPEED | 3,500 RPM |
| SPINDLE BORE TAPER | MT6 x MT4 |
| QUILL DIAMETER | 2.874" |
| QUILL TAPER | MT5 |
| TAILSTOCK QUILL TRAVEL | 5.5118" |
| MAX LONGITUDINAL TRAVEL | 35.433" |
| MAX TURNING LENGHT | 33.858" |
| WEIGHT | 5,952.5 lb |
| Weight | 2700 kg |
FANUC 0i-TF PLUS CONTROL WITH 10.4" COLOR LCD SCREEN
β8i SPINDLE SERVO MOTOR, WITH: MANUAL GUIDE i
AUTOMATIC LUBRICATION IN HEADSTOCK AND SLIDE WAYS & BALL SCREWS
AUTOMATIC SPINDLE SPEED GEAR CHANGER
CUTTING FLUID COOLANT SYSTEM
FULL LENGTH REAR SPLASH GUARD
FRONT MOVEABLE CHIP TROLLEY
FULL ENCLOSED END GUARD
LED WORKING LIGHT
LEVELING BLOCKS
CENTERS AND CENTER SLEEVE
SERVICE TOOLS & TOOLBOX
OPERATION, PROGRAMMING & INSTRUCTION MANUAL
OPTIONAL ACCESSORIES:
10" SK TYPE DIRECT MOUNTED HEAVY DUTY 3-JAW SCROLL, CHUCK (MAX. SPEED: 2800 rpm)
SOFT JAWS FOR 8"/9"/10" 3-JAW CHUCK
10" DIRECT MOUNTED 4-JAW INDEPENDENT CHUCK
ELECTRIC 8-STATION AUTO. TOOL CHANGER TURRET BTP-63, FRONT MOUNT (INDIA MADE)
CHAIN TYPE CHIP CONVEYOR WITH TAIL-END EXIT
NEW DESIGN ROUND TYPE GUARDING
