New APEC MTH-2442 | Bridge (Double Column) Vertical Milling Center

1.888.565.8807
sales@megatelcnc.com
ConditionNew

Overview

Type:
Bridge (Double Column) Vertical Milling Center
Manufacturer:
APEC
Model:
MTH-2442
Condition:
Build To Order
Status:
For Sale

Description

Explore APEC MTH-2442, a new Double Column Vertical Milling Center with 5 axes, 4200x2500x1000 mm travels, 14T table load, 12000 RPM spindle, Heidenhain TNC640 control, and optional 40/60 ATC. Perfect for large-scale precision milling.

X-Axis Travel4,200 mm165.35"
Y-Axis Travel2,500 mm98.425"
Z-Axis Travel1,000 mm39.37"
Distance Between Column2,400 mm94.488"
Spindle Nose to Table Top1,150 mm45.276"
Table Size-X4,000 mm157.48"
Table Size-Y2,060 mm81.102"
Table Load Capacity14 T12,700.6 kg
Standard Spindle TaperHSK100AHSK100A
Standard Spindle Speed12,000 RPM12,000 RPM
Milling Head (2-axis) TypeUniversal head | Mono head | Fork HeadUniversal head | Mono head | Fork Head
A-axis Swivel185°185°
C-axis Rotation360°360°
ATC3232
Optional ATC40 | 6040 | 60
# Axis55
CN ControlHeidenhain TNC640Heidenhain TNC640

Overview

Type:
Bridge (Double Column) Vertical Milling Center
Manufacturer:
APEC
Model:
MTH-2442
Condition:
Build To Order
Status:
For Sale

Description

Explore APEC MTH-2442, a new Double Column Vertical Milling Center with 5 axes, 4200x2500x1000 mm travels, 14T table load, 12000 RPM spindle, Heidenhain TNC640 control, and optional 40/60 ATC. Perfect for large-scale precision milling.

Specifications

Metric

X-Axis Travel165.35"
Y-Axis Travel98.425"
Z-Axis Travel39.37"
Distance Between Column94.488"
Spindle Nose to Table Top45.276"
Table Size-X157.48"
Table Size-Y81.102"
Table Load Capacity12,700.6 kg
Standard Spindle TaperHSK100A
Standard Spindle Speed12,000 RPM
Milling Head (2-axis) TypeUniversal head | Mono head | Fork Head
A-axis Swivel185°
C-axis Rotation360°
ATC32
Optional ATC40 | 60
# Axis5
CN ControlHeidenhain TNC640
