GOODWAY GV-1600

Description

With leading technologies and high-quality components, the SUPER GV CNC vertical
turning center combines heavy-duty, high rigidity, and super large machining
range advantages to provide you with large-sized, asymmetric workpiece turning
capabilities. The optimal reinforced structure of these series can maintain long term
precision even if the table diameter is reached up to 8,000mm. Plus, with the optional
dual ram or live tooling spindle and C-axis, all kinds of complex turning applications
can be done easily, which can meet your needs for today and tomorrow.

Key Highlights:

Super Large Turning Range:
Maximum turning diameter can reach up to Ø 9,000 mm; maximum workpiece
weight can reach up to 300,000 Kg ( GV-8000 series ).

High Rigidity Structure:
The bed, column, and bridge casting components are of Meehanite casting
with a symmetric structure design, which ensures optimal thermal balance and
heavy-duty rigidity.

Powerful High Torque Motors:
The workpiece and live tooling spindles use a high-power 2-speed heavy-duty gearbox motor to provide ample torque output for heavy-duty cutting
applications.

High Efficiency Chip Removal System:
The standard chip wash-down coolant system can flush away a great amount of
chips into the coolant tank, and are sent outside from the machine through the
chip conveyor; this tremendously improves the machine's overall accuracy by
lowering thermal expansion effects to a minimum.

Turning, Milling And Grinding Multi-Tasking Capability:
The optional live tooling spindle provides turning, milling, grinding, drilling,
and tapping capabilities, which greatly increases production efficiency while
saving equipment investment costs.
