GOODWAY GV-1100 VERTICAL CNC LATHE
ConditionNew
New
Experience Unmatched Precision with the GOODWAY GV-1100 Vertical Turning Center
The GOODWAY GV-1100 Vertical Turning Center is engineered to meet the demands of high-precision and heavy-duty machining. With a maximum swing of 1,400 mm, a 40" chuck, and a table load capacity of up to 4,000 kg, this machine is built to handle large, complex components with ease. The Fanuc 0i-TF Plus control system offers advanced precision and user-friendly operation, while the 16-tool automatic changer ensures efficient, continuous machining with minimal downtime.
The GOODWAY GV-1100 is ideal for industries that require reliable, high-performance machining solutions for complex turning applications. Whether you are working with large workpieces or handling demanding production tasks, this vertical turning center delivers outstanding accuracy, stability, and productivity.
Key Features:
• High-Capacity Machining: Handles a maximum swing of 1,400 mm and a table load capacity of up to 4,000 kg, making it ideal for large and heavy components.
• Advanced Chuck System: Equipped with a 40" chuck for secure and stable workpiece holding, even during intense machining operations.
• Precision Control: Features the Fanuc 0i-TF Plus control system, offering advanced functionality, accuracy, and ease of operation for complex turning tasks.
• Automated Tool Changing: Includes a 16-tool automatic changer to support high-efficiency machining and minimize downtime between operations.
• Heavy-Duty Construction: Built with a rigid, stable structure designed for high-precision, heavy-duty turning applications, ensuring consistent accuracy.
• Versatile Applications: Suitable for a wide range of industries, including automotive, aerospace, and large-part manufacturing where precision and load capacity are critical.
Contact us today to learn more about how the GOODWAY GV-1100 can transform your machining operations!
WITH FANUC 0i-TF PLUS CONTROL WITH 15" LCD SCREEN
MANUAL GUIDE-I FOR FANUC 0i-TF PLUS
UPGRADED TO 16 TOOLS ATC MAGAZINE
UPGRADED TO 40" 3 JAWS CHUCK
HYDRAULIC CYLINDER
MAIN SPINDLE MOTOR OUTPUT 37/45KW WITH SPINDLE CHILLER (1.5 TON, 4500 kcal/hr)
2-STEP GEAR BOX
TOOL HOLDER PACKAGE
CF-AXIS WITH DISK BRAKE ON MAIN SPINDLE (GREASE TYPE)
CF-AXIS DRIVE MOTOR Alpha 12/3000i, MAX. SPEED: 9 RPM, MAX. TORQUE: 2280NM
TOOL SPINDLE (SPINDLE MOTOR 7.5/11KW, 2 SPEED GEAR BOX)
BT-50 TOOL SPINDLE WITH TOOL HOLDER PACKAGE PART NO. VK-OBBC
- 2 PCS x OD TOOL HOLDER (SHANK 32 MM) (VK-TBBB)
- 2 PCS x BORING TOOL HOLDER (SHANK 25MM) (VK-TBBC)
- 2 PCS x BORING TOOL HOLDER (SHANK 25MM) (VK-TBBE)
HIGH-LOW GUIDE WAY STRUCTURE WITH BOX WAYS ON ALL AXES
C3 CLASS BALL SCREWS WITH PRETENSION ON ALL AXES
CHIP CONVEYOR (HINGE TYPE) WITH AUTO TIMER
ELECTRICAL CABINET HEAT EXCHANGER
OIL SKIMMER
3 SETS x 90° HEAD
GOODWAY AUTO TOOL SETTER (RENISHAW RP3 PROBE)
MIST COLLECTOR (DUE TO THE COVER IS SEMI-ENCLOSED, THE OIL MIST IS NOT ABLE TO COLLECT COMPLETELY BY THE OIL MIST COLLECTOR)
COOLANT PISTOL WITH PIPE CONTROL BY OPERATION PANEL BUTTON
AIR PISTOL WITH PIPE CONTROL BY OPERATION PANEL BUTTON
70 BAR COOLANT THROUGH SPINDLE SYSTEM
