AWEA LP-4021
ConditionNew
New
Representing AWEA’s “The royal family of bridge machines” of mature manufacturing abilities and advanced technology skills, the SP and LP series bridge-type vertical machining centers combine strong spindle power and high rigidity structure along with high-quality automation equipment and a full product line to provide you with high efficiency, high productivity machining strategies; it can be broadly applied in the automotive, precision mold, aerospace and energy industries.
The LP series can be equipped with an automatic head changer and vertical/horizontal ATC system which turns into a 5-face machining center providing more cutting flexibility to meet your demands of today and tomorrow.
Key Highlights:
✔ The modular spindle design provides cutting flexibility for various working conditions.
✔ High-rigidity roller-type linear guideways on the X, and Y axes offer heavy-duty cutting, fast movement, and low abrasion capabilities.
✔ The Z-axis is adopted with a high rigidity box way which is hardened and precisely ground suitable for heavy-duty cutting conditions. ( Opt. : The Z-axis can be adopted with roller-type linear guideways if equipped with a high-speed direct drive spindle. )
Representing AWEA’s “The royal family of bridge machines” of mature manufacturing abilities and advanced technology skills, the SP and LP series bridge-type vertical machining centers combine strong spindle power and high rigidity structure along with high-quality automation equipment and a full product line to provide you with high efficiency, high productivity machining strategies; it can be broadly applied in the automotive, precision mold, aerospace and energy industries.
The LP series can be equipped with an automatic head changer and vertical/horizontal ATC system which turns into a 5-face machining center providing more cutting flexibility to meet your demands of today and tomorrow.
Key Highlights:
✔ The modular spindle design provides cutting flexibility for various working conditions.
✔ High-rigidity roller-type linear guideways on the X, and Y axes offer heavy-duty cutting, fast movement, and low abrasion capabilities.
✔ The Z-axis is adopted with a high rigidity box way which is hardened and precisely ground suitable for heavy-duty cutting conditions. ( Opt. : The Z-axis can be adopted with roller-type linear guideways if equipped with a high-speed direct drive spindle. )
Metric
| X-Axis Travel | 157.48" |
| Y-Axis Travel | 82.677" |
| Optional Y-Axis Travel | 2,800 mm |
| Z-Axis Travel | 29.921" |
| W-Axis Travel | 1,000 | 1,200 | 1,400 mm |
| Distance Between Column | 90.551" |
| Spindle Nose to Table Top | 37.795" |
| Table Surface to Spindle Dist. | 1,200 | 1,400 | 1,600 mm |
| Table Size-X | 158.27" |
| Table Size-Y | 79.134" |
| Table Load Capacity | 26,455.4 lb |
| Standard Spindle Taper | CAT50 |
| Optional Spindle Taper | CAT40 |
| Standard Spindle Speed | 6,000 RPM |
| Max. Feed Speed | 4,000 | 8,000 | 10,000 | 12,000 | 15,000 RPM |
| ATC | 32 |
| Optional ATC | 40 | 60 | 90 | 120 |
| # Axis | 3 |
| CN Control | Fanuc | Mitsubishi | Heidenhain | Fagor |
