AWEA VP-5012 BRIDGE TYPE MILLING CENTER
ConditionNew
New
Introducing AWEA's VP Series, where mature manufacturing abilities and advanced technology converge to redefine machining excellence. These bridge-type vertical machining centers epitomize innovation, blending advanced design concepts with a robust machine structure to deliver the ultimate in machining power within the most compact floor space. Renowned for their cost-effectiveness, the VP Series stands as a beacon of efficiency in the industry. With a modular design adopted across all series, this lineup offers versatility like never before, providing high-performance solutions tailored to meet the demands of today and tomorrow. Step into the future of machining with the AWEA VP Series and unlock a world of limitless possibilities.
Key Highlights:
• Ultra Performance Bridge Type Vertical Machining Centers optimum rigidity, accuracy, and efficiency.
• The modular spindle design provides cutting flexibility for various working conditions.
• High rigidity linear guideways on the X, and Y axes.
• The Z-axis is adopted with a high rigidity box way which is hardened and precisely ground suitable for heavy-duty cutting conditions.
FANUC 0I-MF PLUS WITH 10.4 LCD SCREEN
AICCII (200 BLOCK LOOK-AHEAD) + 2GB DATA SERVER
SPINDLE MOTOR UPGRADE TO 15KW (20/25 HP)
6,000 RPM GEAR DRIVEN SPINDLE, CAT50
32 TOOL ATC MAGAZINE
20 BAR COOLANT THROUGH SPINDLE SYSTEM WITH PUMP AND TANK
AIR THROUGH SPINDLE
SPINDLE COOLING SYSTEM
CENTRALIZED AUTOMATIC LUBRICATING SYSTEM
EXTENSION OPERATOR DOOR
SCREW TYPE CHIP AUGER X 2
CATERPILLAR TYPE CHIP CONVEYOR
AUTO. POWER OFF SYSTEM
AIR GUN & COOLANT GUN
ROOF ENCLOSURE
OIL SKIMMER
Introducing AWEA's VP Series, where mature manufacturing abilities and advanced technology converge to redefine machining excellence. These bridge-type vertical machining centers epitomize innovation, blending advanced design concepts with a robust machine structure to deliver the ultimate in machining power within the most compact floor space. Renowned for their cost-effectiveness, the VP Series stands as a beacon of efficiency in the industry. With a modular design adopted across all series, this lineup offers versatility like never before, providing high-performance solutions tailored to meet the demands of today and tomorrow. Step into the future of machining with the AWEA VP Series and unlock a world of limitless possibilities.
Key Highlights:
• Ultra Performance Bridge Type Vertical Machining Centers optimum rigidity, accuracy, and efficiency.
• The modular spindle design provides cutting flexibility for various working conditions.
• High rigidity linear guideways on the X, and Y axes.
• The Z-axis is adopted with a high rigidity box way which is hardened and precisely ground suitable for heavy-duty cutting conditions.
Metric
| X-Axis Travel | 196.85" |
| Y-Axis Travel | 47.244" |
| Z-Axis Travel | 29.921" |
| Distance Between Column | 51.181" |
| Spindle Nose to Table Top | 37.795" |
| Table Size-X | 196.85" |
| Table Size-Y | 43.307" |
| Table Load Capacity | 17,637 lb |
| Standard Spindle Taper | CAT50 |
| Standard Spindle Speed | 6,000 RPM |
| Rapid Feedrate (Traverse) | 8/24/20 m/min |
| ATC | 32 |
| Max Tool Length | 13.78" |
| Max Tool Weight | 33.1 lb |
| # Axis | 3 |
| CN Control | Fanuc 0i-MF Plus |
FANUC 0I-MF PLUS WITH 10.4 LCD SCREEN
AICCII (200 BLOCK LOOK-AHEAD) + 2GB DATA SERVER
SPINDLE MOTOR UPGRADE TO 15KW (20/25 HP)
6,000 RPM GEAR DRIVEN SPINDLE, CAT50
32 TOOL ATC MAGAZINE
20 BAR COOLANT THROUGH SPINDLE SYSTEM WITH PUMP AND TANK
AIR THROUGH SPINDLE
SPINDLE COOLING SYSTEM
CENTRALIZED AUTOMATIC LUBRICATING SYSTEM
EXTENSION OPERATOR DOOR
SCREW TYPE CHIP AUGER X 2
CATERPILLAR TYPE CHIP CONVEYOR
AUTO. POWER OFF SYSTEM
AIR GUN & COOLANT GUN
ROOF ENCLOSURE
OIL SKIMMER
